New
ASUS PRIME H610M-K D4 Intel 12th Gen Motherboard PCIe 4.0 DDR4 1xM.2 slots USB 3.2 Gen 1

ASUS

ASUS PRIME H610M-K D4 Intel 12th Gen Motherboard PCIe 4.0 DDR4 1xM.2 slots USB 3.2 Gen 1

1 year warranty

  • Availability: In Stock
75.000 JOD
Get offer by email
  • SH Certified / inspected
  • Delivery across Jordan
  • 1 year warranty
  • Expert help on WhatsApp

Product Specifications

Full technical details for this system

ASUS • PRIME
PRIME H610M-K D4
INTEL H610 • LGA1700 • DDR4 • MICRO ATX
A compact Intel LGA1700 motherboard designed for reliable everyday and gaming systems, featuring DDR4 memory support, PCIe 4.0 graphics, M.2 NVMe storage, SATA connectivity, Gigabit Ethernet and ASUS 5X Protection III technologies.
PRIME LGA1700 H610 DDR4 PCIe 4.0 M.2
LGA1700 CPU SOCKET
64GB MAX DDR4
PCIe 4.0 GPU SLOT
1× M.2 SLOT
ASUS PRIME PLATFORM

Reliable Intel Performance in a Compact Design.

The PRIME H610M-K D4 provides a practical foundation for Intel LGA1700 systems, combining DDR4 memory support, PCIe 4.0 graphics, M.2 NVMe storage and essential connectivity in a compact Micro ATX form factor.

01

Intel LGA1700 Platform

Supports Intel Core processors from the 12th, 13th and 14th generations, along with compatible Pentium Gold and Celeron processors.

02

PCIe 4.0 Graphics

A PCIe 4.0 x16 SafeSlot Core expansion slot provides high-speed connectivity for modern dedicated graphics cards.

03

M.2 NVMe Storage

The dedicated M.2 Key M slot supports 2242, 2260 and 2280 drives with PCIe 3.0 x4 and SATA modes.

PRIME H610M-K D4

Essential Features. Built for Everyday Performance.

A dependable Micro ATX platform with DDR4 memory, PCIe 4.0 graphics, M.2 storage, Gigabit networking and ASUS hardware protection technologies.

64GB MAX DDR4
PCIe 4.0 GPU SLOT
1× M.2 STORAGE
1GbE LAN

Technical Specifications

Processor & Chipset
CPU Socket
Intel LGA1700
Supported Processors
Intel Core 14th / 13th / 12th Gen
Additional CPU Support
Intel Pentium Gold / Celeron
Chipset
Intel H610
CPU Technology
Intel Turbo Boost 2.0 / Turbo Boost Max 3.0
Memory
Memory Type
DDR4
Memory Slots
2 × DIMM
Maximum Capacity
64GB
Memory Architecture
Dual Channel
Maximum Official Speed
DDR4-3200
Supported Speeds
3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133
Memory Profiles
Intel XMP
Memory Type
Non-ECC Unbuffered DIMM
Graphics & Expansion
Primary PCIe Slot
1 × PCIe 4.0 x16
Primary Slot Mode
x16
Secondary PCIe Slot
1 × PCIe 3.0 x1
PCIe Reinforcement
SafeSlot Core
HDMI
1 × HDMI
HDMI Resolution
Up to 4K @ 60Hz
D-Sub
1 × D-Sub
Storage
M.2 Slots
1 × M.2 Key M
M.2 Interface
PCIe 3.0 x4 / SATA
Supported M.2 Sizes
2242 / 2260 / 2280
SATA
4 × SATA 6Gb/s
M.2 / SATA Sharing
SATA6G_4 Disabled When M.2 SATA Mode Is Used
Networking
LAN Controller
Realtek 1Gb Ethernet
LAN Speed
10 / 100 / 1000 Mbps
Network Features
ASUS LANGuard
USB Connectivity
Rear USB 3.2 Gen 1
2 × Type-A — 5Gbps
Rear USB 2.0
4 × Type-A
Front USB 3.2 Gen 1
1 Header — 2 Additional Ports
Front USB 2.0
1 Header — 2 Additional Ports
Audio
Audio Codec
Realtek 7.1 Surround Sound HD Audio
Playback
Up to 24-bit / 192kHz
Audio Features
Jack Detection / Multi-Streaming / Jack Retasking
Audio Shielding
Dedicated Audio PCB Layers
Digital Audio
S/PDIF Out Header
Rear I/O
USB
2 × USB 3.2 Gen 1 + 4 × USB 2.0
Video
HDMI + D-Sub
LAN
1 × Realtek 1Gb Ethernet
Audio
3 × Audio Jacks
Keyboard / Mouse
PS/2 Combo Port
Internal I/O
CPU Fan Header
1 × 4-pin
Chassis Fan Header
1 × 4-pin
Main Power
1 × 24-pin ATX
CPU Power
1 × 8-pin +12V
RGB
1 × RGB Header
Clear CMOS
1 × Header
TPM
SPI TPM Header
S/PDIF
1 × S/PDIF Out Header
ASUS Protection & Features
Protection
ASUS 5X Protection III
VRM
DIGI+ VRM
LAN Protection
LANGuard
Overvoltage Protection
ASUS Overvoltage Protection
PCIe Protection
SafeSlot Core
Rear I/O
Stainless-Steel Back I/O
Q-Design
Q-DIMM / Q-Slot
Cooling
VRM Cooling
Aluminum Heatsink
CPU Fan Control
Fan Xpert
Chassis Fan Control
Fan Xpert
BIOS & Software
BIOS
128Mb Flash ROM / UEFI AMI BIOS
BIOS Update
ASUS EZ Flash 3
BIOS Recovery
ASUS CrashFree BIOS 3
BIOS Interface
ASUS UEFI BIOS EZ Mode
System Software
Armoury Crate / AI Suite 3
Utilities
TurboV EVO / EPU / DIGI+ VRM / Fan Xpert
RGB & Lighting
RGB Header
1 × RGB Header
Lighting Control
ASUS Lighting Control
Operating System
Supported OS
Windows 11 64-bit / Windows 10 64-bit
Physical Specifications
Form Factor
Micro ATX
Dimensions
23.4 × 20.3cm
Dimensions
9.2 × 8.0 inches
Product Identification
Model
PRIME H610M-K D4
Brand
ASUS
Series
PRIME
Chipset
Intel H610
Socket
LGA1700
Memory
DDR4
Form Factor
Micro ATX
ASUS PRIME H610M-K D4 INTEL H610 • LGA1700 • DDR4 • PCIe 4.0 • 1× M.2 • 1GbE • MICRO ATX
