MSI PRO B760M-P DDR5 Intel 13th Gen Motherboard PCIe 4.0 DDR5 2xM.2 PCIe 4.0 Mainboard

MSI

MSI PRO B760M-P DDR5 Intel 13th Gen Motherboard PCIe 4.0 DDR5 2xM.2 PCIe 4.0 Mainboard

1 year warranty

  • Availability: In Stock
110.000 JOD
Get offer by email
  • SH Certified / inspected
  • Delivery across Jordan
  • 1 year warranty
  • Expert help on WhatsApp

Product Specifications

Full technical details for this system

MSI • PRO SERIES
PRO B760M-P
INTEL B760 • LGA1700 • DDR5 • MICRO ATX
A reliable Micro ATX motherboard designed for modern Intel desktop systems, featuring DDR5 memory support, PCIe 4.0 graphics, dual PCIe 4.0 M.2 storage, Gigabit Ethernet and MSI PRO technologies for dependable performance and everyday productivity.
MSI PRO LGA1700 B760 DDR5 PCIe 4.0 2× M.2
LGA1700 CPU SOCKET
256GB MAX DDR5
2× M.2 PCIe 4.0 x4
1GbE GIGABIT LAN
MSI PRO PLATFORM

Practical Performance. Professional Reliability.

The PRO B760M-P provides a balanced foundation for Intel desktop systems with four DDR5 memory slots, PCIe 4.0 expansion, two high-speed M.2 NVMe slots, four SATA ports, Gigabit networking and a comprehensive selection of modern I/O.

01

Intel LGA1700 Platform

Supports Intel Core processors from the 14th, 13th and 12th generations, along with compatible Pentium Gold and Celeron processors.

02

DDR5 Memory Boost

Four DDR5 DIMM slots support up to 256GB of memory and speeds of up to DDR5-6800+ MT/s through overclocking.

03

Dual Gen4 M.2 Storage

Two PCIe 4.0 x4 M.2 slots provide high-speed NVMe storage connectivity with bandwidth of up to 64Gbps.

MSI PRO B760M-P

Built for Modern Intel Systems.

A clean and practical Micro ATX platform combining DDR5, PCIe 4.0, Gen4 NVMe storage, MSI Steel Armor and professional networking for a dependable PC foundation.

256GB MAX DDR5
6800+ MT/s OC
2× M.2 GEN4 x4
64Gbps M.2 BANDWIDTH

Technical Specifications

Processor & Chipset
CPU Socket
Intel LGA1700
Processor Support
Intel Core 14th / 13th / 12th Gen
Additional CPU Support
Intel Pentium Gold / Celeron
Chipset
Intel B760
DDR5 Memory
Memory Type
DDR5
Memory Slots
4 × DDR5 DIMM
Maximum Capacity
256GB
Memory Architecture
Dual-Controller Dual-Channel
Maximum OC Speed
DDR5-6800+ MT/s
1DPC 1R
Up to 6800+ MT/s
1DPC 2R
Up to 6400+ MT/s
2DPC 1R
Up to 6000+ MT/s
2DPC 2R
Up to 5600+ MT/s
Memory Profiles
Intel XMP 3.0
Memory Type
Non-ECC Unbuffered
PCI Express & Expansion
Primary PCIe Slot
1 × PCIe 4.0 x16
Primary Slot Source
CPU
Secondary Slots
2 × PCIe 4.0 x1
Secondary Slot Source
Intel B760 Chipset
GPU Protection
MSI Steel Armor
Storage
M.2 Slots
2 × M.2 Key M
M.2_1 Interface
PCIe 4.0 x4
M.2_1 Source
CPU
M.2_1 Sizes
2242 / 2260 / 2280
M.2_2 Interface
PCIe 4.0 x4 / SATA Mode
M.2_2 Source
Intel B760 Chipset
M.2_2 Sizes
2242 / 2260 / 2280
M.2 Bandwidth
Up to 64Gbps
SATA
4 × SATA 6Gb/s
Storage RAID
RAID 0 / 1 / 5 / 10
Storage Note
SATA5 unavailable when M.2 SATA SSD is installed in M.2_2
Networking
LAN Controller
Realtek RTL8111H
LAN Type
Gigabit Ethernet
Maximum Speed
1Gbps
Display Outputs
HDMI
1 × HDMI 1.4
HDMI Maximum
4K @ 30Hz
DisplayPort
1 × DisplayPort 1.4
DisplayPort Maximum
4K @ 60Hz
VGA
1 × VGA
VGA Maximum
Up to 2048 × 1536 @ 50Hz
Graphics Requirement
Processor with Integrated Graphics Required
USB Connectivity
Rear USB 2.0
4 × Type-A
Front USB 2.0
4 × Type-A
Rear USB 5Gbps
1 × Type-A
Front USB 5Gbps
2 × Type-A
Rear USB 10Gbps
1 × Type-C
Audio
Audio Codec
Realtek ALC897
Audio Channels
7.1-Channel High Definition Audio
Audio Technology
MSI Audio Boost
Audio Design
Isolated Audio Signal
Cooling & Thermal Design
Cooling Technology
Frozr AI Cooling
CPU Fan Header
1 × CPU Fan
System Fan Headers
2 × System Fan
Fan Management
Automatic CPU & GPU Temperature Detection
Power & Design
CPU Power
1 × CPU Power Connector
Main Power
1 × ATX Power Connector
Power Technology
MSI Core Boost
Memory Technology
MSI Memory Boost
RGB & Lighting
RGB Header
1 × JRGB LED Connector
Lighting Software
MSI Mystic Light
RGB Expansion
Mystic Light Extension
Internal I/O
CPU Fan
1 × Header
System Fans
2 × Headers
Front Panel
2 × JFP Headers
Chassis Intrusion
1 × JCI Header
Front Audio
1 × JAUD Header
TPM
1 × TPM 2.0 Header
RGB
1 × JRGB Header
COM Port
1 × JCOM Header
Printer Port
1 × JLPT Header
MSI PRO Features
CPU Performance
Core Boost
Memory Technology
Memory Boost
PCIe Protection
Steel Armor
Storage Technology
Lightning Gen4
Audio Technology
Audio Boost
Thermal Technology
Frozr AI Cooling
Diagnostics
EZ Debug LED
BIOS & Software
BIOS Interface
MSI Click BIOS
Memory Profiles
Intel XMP 3.0
System Software
MSI Center
RGB Software
MSI Mystic Light
Operating System
Supported OS
Windows 11 64-bit / Windows 10 64-bit
Physical Specifications
Form Factor
Micro ATX
Dimensions
243.84 × 243.84mm
Product Identification
Model
PRO B760M-P
Brand
MSI
Series
PRO Series
Chipset
Intel B760
Socket
LGA1700
Memory
DDR5
Memory Slots
4 × DIMM
Maximum Memory
256GB
Form Factor
Micro ATX
MSI PRO B760M-P INTEL B760 • LGA1700 • DDR5 • PCIe 4.0 • 2× GEN4 M.2 • GIGABIT LAN • MICRO ATX
