New
GIGABYTE B860 DS3H WIFI6E Intel Core Ultra (Series 2) LGA 1851 Motherboard, ATX, DDR5, 3X M.2, PCIe 5.0, USB-C, WIFI6E, 2.5GbE LAN, EZ-Latch

Gigabyte

GIGABYTE B860 DS3H WIFI6E Intel Core Ultra (Series 2) LGA 1851 Motherboard, ATX, DDR5, 3X M.2, PCIe 5.0, USB-C, WIFI6E, 2.5GbE LAN, EZ-Latch

1 year warranty

  • Availability: In Stock
135.000 JOD
Get offer by email
  • SH Certified / inspected
  • Delivery across Jordan
  • 1 year warranty
  • Expert help on WhatsApp

Product Specifications

Full technical details for this system

GIGABYTE • ULTRA DURABLE
B860 DS3H WIFI6E
INTEL B860 • LGA1851 • DDR5 • PCIe 5.0 • WI-FI 6E
A full-size ATX motherboard designed for Intel Core Ultra processors, combining high-speed DDR5 memory, PCIe 5.0 graphics, next-generation NVMe storage, 2.5Gb Ethernet and Wi-Fi 6E connectivity with GIGABYTE's Ultra Durable engineering.
GIGABYTE B860 LGA1851 DDR5 PCIe 5.0 WI-FI 6E
LGA1851 CPU SOCKET
256GB MAX DDR5
PCIe 5.0 x16 GRAPHICS
2.5GbE LAN
GIGABYTE ULTRA DURABLE PLATFORM

Built for the Next Generation of Intel.

The B860 DS3H WIFI6E combines Intel's B860 platform with DDR5 memory, PCIe 5.0 graphics, Gen5 NVMe storage, 2.5Gb Ethernet and Wi-Fi 6E in a versatile ATX motherboard designed for modern gaming, productivity and high-performance systems.

01

Intel Core Ultra Platform

Built around the Intel B860 chipset and LGA1851 socket for Intel Core Ultra desktop processors.

02

PCIe 5.0 & Gen5 NVMe

A PCIe 5.0 x16 graphics slot and PCIe 5.0 M.2 interface provide a high-bandwidth platform for next-generation hardware.

03

Wi-Fi 6E & 2.5GbE

High-speed wired and wireless connectivity with 2.5Gb Ethernet, Wi-Fi 6E and Bluetooth 5.3.

GIGABYTE B860 DS3H WIFI6E

Next-Gen Connectivity. Ultra Durable Design.

A modern ATX platform combining DDR5, PCIe 5.0, Gen5 M.2 storage, 2.5GbE and Wi-Fi 6E for powerful Intel Core Ultra systems.

256GB MAX DDR5
PCIe 5.0 x16 GPU
GEN5 M.2 NVMe
WI-FI 6E WIRELESS

Technical Specifications

Processor & Chipset
CPU Socket
Intel LGA1851
Processor Support
Intel Core Ultra Processors
Chipset
Intel B860
DDR5 Memory
Memory Type
DDR5
Memory Slots
4 × DDR5 DIMM
Maximum Capacity
256GB
Memory Architecture
Dual Channel
Supported Speed
DDR5-6400 / 5600 MT/s
Memory Profiles
Intel XMP
Memory Type
ECC Unbuffered / Non-ECC Unbuffered
PCI Express & Expansion
Primary Graphics Slot
1 × PCIe 5.0 x16
Primary Slot Source
CPU
Additional Expansion
4 × PCIe 4.0 x1
Additional Slot Source
Intel B860 Chipset
PCIe Technology
PCI Express 5.0 / 4.0
M.2 & Storage
M.2 Slots
2 × M.2
Primary M.2
PCIe 5.0 x4 / x2
Primary M.2 Source
CPU
Secondary M.2
PCIe 4.0 x4 / x2
Secondary M.2 Source
Intel B860 Chipset
Supported M.2 Sizes
22110 / 2580 / 2280
M.2 Type
PCIe NVMe SSD Only
M.2 Technology
M.2 EZ-Latch Plus
SATA
4 × SATA 6Gb/s
RAID Support
RAID 0 / 1 / 5 / 10
Networking
LAN Controller
Realtek 2.5GbE
LAN Speed
2.5Gbps
Wireless
Wi-Fi 6E
Wi-Fi Bands
2.4GHz / 5GHz / 6GHz
Wi-Fi Standard
802.11 a/b/g/n/ac/ax
Wi-Fi Channel Width
Up to 160MHz
Bluetooth
Bluetooth 5.3
Display Outputs
HDMI
1 × HDMI 2.1
HDMI Maximum
4096 × 2160 @ 60Hz
DisplayPort
1 × DisplayPort 2.1
DisplayPort Maximum
3840 × 2160 @ 144Hz
Graphics Source
Processor Integrated Graphics
USB Connectivity
Rear USB Type-C
1 × USB 3.2 Gen 2x2
Rear USB Type-A
1 × USB 3.2 Gen 2
Rear USB 2.0
4 × USB 2.0/1.1
Front USB Type-C
1 × USB 3.2 Gen 1
Front USB 3.2
2 × USB 3.2 Gen 1
Internal USB 2.0
4 × USB 2.0/1.1
Audio
Audio Codec
Realtek Audio CODEC
Audio Type
High Definition Audio
Audio Channels
2 / 4 / 5.1 / 7.1-Channel
Digital Audio
S/PDIF Out
Cooling & Fan Headers
CPU Fan Header
1 × CPU Fan
CPU / Pump Header
1 × CPU Fan / Water Cooling Pump
System Fan Headers
2 × System Fan
System Fan / Pump
2 × System Fan / Water Cooling Pump
RGB & Lighting
ARGB Headers
3 × Addressable RGB Gen2
RGB Header
1 × RGB LED
Lighting Software
GIGABYTE RGB Fusion
GIGABYTE Features
Motherboard Design
Ultra Durable
M.2 Installation
M.2 EZ-Latch Plus
BIOS Flashing
Q-Flash Plus
System Diagnostics
Q-Flash Plus Button
Software Platform
GIGABYTE Control Center
Internal I/O
Main Power
1 × 24-Pin ATX
CPU Power
1 × 8-Pin ATX 12V
Front Panel
1 × Front Panel Header
Front Audio
1 × Front Audio Header
S/PDIF
1 × S/PDIF Out Header
TPM
1 × TPM Header
Serial
1 × Serial Port Header
Physical Specifications
Form Factor
ATX
Product Identification
Brand
GIGABYTE
Model
B860 DS3H WIFI6E
Chipset
Intel B860
Socket
LGA1851
CPU Platform
Intel Core Ultra Processors
Memory
DDR5
Memory Slots
4 × DIMM
Maximum Memory
256GB
Graphics Interface
PCIe 5.0 x16
M.2
2 × M.2
LAN
2.5GbE
Wireless
Wi-Fi 6E
Bluetooth
5.3
Form Factor
ATX
GIGABYTE B860 DS3H WIFI6E INTEL B860 • LGA1851 • DDR5 • PCIe 5.0 • 2× M.2 • WI-FI 6E • 2.5GbE • ATX
